RX6800XT-16GD6

Process and core code:

Navi 21/7nm

Unity shader:

4608

Core frequency:

Standard frequency 2015-2250MHz, overclocking 2065-2310 (game / acceleration frequency, default standard frequency)

GPU memory speed:

16Gbps

Capacity and specifications for GPU memory:

16G/256bit/GDDR6

Infinity Cache:

128MB

3D Features:

Full DirectX 12/Ray Tracing

OS characteristics include:

Win10 64

GPU Cooler：

YT7A(3 fans+ARGB sync light)

Fan Features:

4pin, speed adjustment, display speed value

Other features:

AMD LiquidVR™ , AMD FreeSync™ 2  Radeon™ VR Ready

Bus interface:

PCI-Express 4.0 x16

Output port:

DP(1.4 with DSC) *3 + HDMI(2.1 VRR and FRL)

Max Resolution:

7680*4320（DP）

Sli/Crossfire：

not supported

Power supply design:

10+2 phase

External power source:

8+8 PIN（Power requirement 750W or more）
