Process and core code: | Navi 22/7nm |
Unity shader: | 2560 |
Core frequency: | Standard frequency 2495-2600MHz (game/acceleration) |
GPU memory speed: | 18Gbps |
Capacity and specifications for GPU memory: | 12G/192bit/GDDR6 |
Infinity Cache: | 96MB |
3D Features: | Full DirectX 12/Ray Tracing (DXR) |
OS characteristics include: | Win10 64 |
GPU Cooler: | YT6C-G (3 fans + 6 6mm heat pipes + ARGB synchronization) |
Fan Features: | 4pin, speed adjustment, display speed value |
Other features: | AMD LiquidVR™ , AMD FreeSync™ 2 Radeon™ VR Ready |
Bus interface: | PCI-Express 4.0 |
Output port: | DP(1.4 with DSC) *3 + HDMI(2.1 VRR and FRL) |
Max Resolution: | 7680*4320(DP & HDMI) |
Sli/Crossfire: | not supported |
Power supply design: | 9+3 phases (core 7+2, memory 2+1) |
External power source: | 8+6 PIN(Recommended power supply above 750W) |
Size/Weight: | 310*125*55mm |
