NVIDIA A800

The A800 PCIe 40 GB is a professional graphics card by NVIDIA, launched on November 8th, 2022. Built on the 7 nm process, and based on the GA100 graphics processor, the card does not support DirectX. Since A800 PCIe 40 GB does not support DirectX 11 or DirectX 12, it might not be able to run all the latest games. The GA100 graphics processor is a large chip with a die area of 826 mm² and 54,200 million transistors. It features 6912 shading units, 432 texture mapping units, and 160 ROPs. Also included are 432 tensor cores which help improve the speed of machine learning applications. NVIDIA has paired 40 GB HBM2e memory with the A800 PCIe 40 GB, which are connected using a 5120-bit memory interface. The GPU is operating at a frequency of 765 MHz, which can be boosted up to 1410 MHz, memory is running at 1215 MHz.
Being a dual-slot card, the NVIDIA A800 PCIe 40 GB draws power from an 8-pin EPS power connector, with power draw rated at 250 W maximum. This device has no display connectivity, as it is not designed to have monitors connected to it. A800 PCIe 40 GB is connected to the rest of the system using a PCI-Express 4.0 x16 interface. The card measures 267 mm in length, 111 mm in width, and features a dual-slot cooling solution.

NVIDIA A800 Specification



A800

40GB PCle

A800

80GB PCle

A800

80GB SXM

FP649.7 TFLOPS
FP64 Tensor Core19.5TFLOPS
FP3219.5TFLOPS
Tensor Float 32 (TF32)156 TFLOPS | 312 TFLOPS*
BFLOAT 16 Tensor Core312 TFLOPS | 624 TFLOPS*
INT8 Tensor Core624TOPSI 1248 TOPS*
GPU Memory40GB HBM280GB HBM2e80GB HBM2e
GPU Memory Bandwidth1,555GB/s1,935GB/s2,039GB/s
Max Thermal Design Power (TDP)250W300W400W***

Multi-Instance

GPU

Upto7MIGs@

5GB

Upto7MIGs@

10GB

Upto7MIGs@

10GB

Form FactorPCle (dual-slot air cooled or single-slot liquid cooled)SXM
Interconnect

NVIDIA NVLink" Bridge for 2 GPUs:

400GB/s

PCle Gen4: 64GB/s

NVLink: 400GB/s

PCle Gen4: 64GB/s

Server Options

Partner and NVIDIA-Certified

Systems" with 1-8 GPUs

NVIDIA HGX™

A800-Partner and

NVIDIA-Certified

Systems with 4 or

8 GPUs

NVIDIA A100 vs A800 : 80GB PCIe Version

Specifications

A100
80GB PCIe

A800
80GB PCIe

FP64

9.7 TFLOPS

FP64 Tensor Core

19.5 TFLOPS

FP32

19.5 TFLOPS

Tensor Float 32

156 TFLOPS

BFLOAT 16 Tensor Core

312 TFLOPS

FP16 Tensor Core

312 TFLOPS

INT8 Tensor Core

624 TOPS

GPU Memory

80 GB HBM2

GPU Memory Bandwifth

1,935 GB/s

TDP

300 W

Multi-Instance GPU

Up to 7 MIGs @ 10 GB

Interconnect

NVLink : 600 GB/s
PCIe Gen4 : 64 GB/s

NVLink : 400 GB/s
PCIe Gen4 : 64 GB/s

Server Options

1-8 GPUs

NVIDIA A100 vs A800 : 80GB SXM Version

Specifications

A100
80GB SXM

A800
80GB SXM

FP64

9.7 TFLOPS

FP64 Tensor Core

19.5 TFLOPS

FP32

19.5 TFLOPS

Tensor Float 32

156 TFLOPS

BFLOAT 16 Tensor Core

312 TFLOPS

FP16 Tensor Core

312 TFLOPS

INT8 Tensor Core

624 TOPS

GPU Memory

80 GB HBM2

GPU Memory Bandwifth

2,039 GB/s

TDP

400 W

Multi-Instance GPU

Up to 7 MIGs @ 10 GB

Interconnect

NVLink : 600 GB/s
PCIe Gen4 : 64 GB/s

NVLink : 400 GB/s
PCIe Gen4 : 64 GB/s

Server Options

4/ 8 / 16 GPUs

4 / 8 GPUs

NVIDIA A100 vs A800 : 40GB PCIe Version

Specifications

A100
40GB PCIe

A800
40GB PCIe

FP64

9.7 TFLOPS

FP64 Tensor Core

19.5 TFLOPS

FP32

19.5 TFLOPS

Tensor Float 32

156 TFLOPS

BFLOAT 16 Tensor Core

312 TFLOPS

FP16 Tensor Core

312 TFLOPS

INT8 Tensor Core

624 TOPS

GPU Memory

40 GB HBM2

GPU Memory Bandwifth

1,555 GB/s

TDP

250 W

Multi-Instance GPU

Up to 7 MIGs @ 10 GB

Interconnect

NVLink : 600 GB/s
PCIe Gen4 : 64 GB/s

NVLink : 400 GB/s
PCIe Gen4 : 64 GB/s

Server Options

1-8 GPUs

Graphics card performance comparison

    • GeForce RTX 208083%
    • GeForce RTX 2080 SUPER87%
    • GeForce RTX 3060 Ti89%
    • Radeon RX 6700 XT91%
    • GeForce RTX 2080 Ti98%
    • Radeon RX 6750 XT98%
    • A800 PCIe 40 GB100%
    • GeForce RTX 3070104%
    • GeForce RTX 3070 Ti112%
    • Radeon RX 6800115%
    • Radeon RX 6800 XT131%
    • GeForce RTX 3080136%
